How to install and integrate DKIM with OpenDKIM and Postfix on a CentOS 6 VPS

Leave reply

how-to-install-and-integrate-opendkim-with-postfix-on-a-centos-6-vpsThis tutorial is part 5 of the mailserver set-up with virtual users and domains using Postfix and Dovecot series. It goes through the steps of installing and integrating OpenDKIM in Postfix on a CentOS 6 Linux VPS.

After completing this tutorial you will end-up having OpenDKIM adding digital signatures to your emails, thus making the mailserver set-up even more robust and professional.

Also, learn how to do this on a Debian Squeeze Linux VPS: Install and Configure openDKIM on Debian Squeeze.

What is OpenDKIM?
It is a digital email signing/verification technology, which is already supported by some common mail providers. In general, DKIM means digitally signing all messages on the mail-server to verify the message was actually sent from the domain in question and was not spam

UPDATE THE SYSTEM

Before going any further, make sure you’re in a screen session and your system is fully up-to-date by running:

## screen -U -S opendkim-screen
## yum update

ENABLE EPEL REPOSITORY

OpenDKIM is available in the EPEL repository, so we need to enable it on the system before we can install OpenDKIM

## wget -P /tmp http://mirror.pnl.gov/epel/6/i386/epel-release-6-8.noarch.rpm
## rpm -Uvh /tmp/epel-release-6-8.noarch.rpm
## rm -f /tmp/epel-release-6-8.noarch.rpm

INSTALL OPENDKIM

Install the package using yum:

## yum install opendkim

CONFIGURE OPENDKIM

Next thing to do is to configure OpenDKIM. Its main configuration file is located in /etc/opendkim.conf, so before making any changes create a backup and add/edit the following:

## cp /etc/opendkim.conf{,.orig}
## vim /etc/opendkim.conf
AutoRestart             Yes
AutoRestartRate         10/1h
LogWhy                  Yes
Syslog                  Yes
SyslogSuccess           Yes
Mode                    sv
Canonicalization        relaxed/simple
ExternalIgnoreList      refile:/etc/opendkim/TrustedHosts
InternalHosts           refile:/etc/opendkim/TrustedHosts
KeyTable                refile:/etc/opendkim/KeyTable
SigningTable            refile:/etc/opendkim/SigningTable
SignatureAlgorithm      rsa-sha256
Socket                  inet:8891@localhost
PidFile                 /var/run/opendkim/opendkim.pid
UMask                   022
UserID                  opendkim:opendkim
TemporaryDirectory      /var/tmp

SET-UP PUBLIC/PRIVATE KEYS

Generate set of keys for your mydomain.com domain name:

## mkdir /etc/opendkim/keys/mydomain.com
## opendkim-genkey -D /etc/opendkim/keys/mydomain.com/ -d mydomain.com -s default
## chown -R opendkim: /etc/opendkim/keys/mydomain.com
## mv /etc/opendkim/keys/mydomain.com/default.private /etc/opendkim/keys/mydomain.com/default

add mydomain.com to OpenDKIM’s key table by adding the following record in /etc/opendkim/KeyTable

default._domainkey.mydomain.com mydomain.com:default:/etc/opendkim/keys/mydomain.com/default

next, edit /etc/opendkim/SigningTable and add the following record to OpenDKIM’s signing table:

*@mydomain.com default._domainkey.mydomain.com

and add your domain and your hostname as trusted hosts in /etc/opendkim/TrustedHosts:

127.0.0.1
mydomain.com
host.mydomain.com

assuming the domain in question is ‘mydomain.com’ and server’s hostname is set to ‘host.mydomain.com’

finally, edit your mydomain.com DNS zone and add the TXT record from /etc/opendkim/keys/mydomain.com/default.txt

default._domainkey      IN      TXT     ( "v=DKIM1; k=rsa; "
          "p=MIGfMA0GCSqGSIb3DQEBAQUAA4GNADCBiQKBgQDApHRr7ZmXRaAB+RQRbP4VdMwIrIHIP18KFtXRsv/xpWc0Gix6ZXN13fcG03KNGKZo2PY+csPkGC5quDnH5V0JEhDZ78KcDWFsU6u4fr9ktVAdt6P7jWXjcyqdHOZ8+YN4cAeU4lRFNgQvdupIcByYwzPYMgBFHfJm9014HvRqhwIDAQAB" )  ; ----- DKIM key default for mydomain.com

it is also a good idea to add an SPF record if you haven’t already

mydomain.com. 14400 IN TXT "v=spf1 a mx ~all"

you can verify your dkim TXT record is valid using dig for example:

## dig +short default._domainkey.mydomain.com TXT

"v=DKIM1\; k=rsa\; " "p=MIGfMA0GCSqGSIb3DQEBAQUAA4GNADCBiQKBgQDApHRr7ZmXRaAB+RQRbP4VdMwIrIHIP18KFtXRsv/xpWc0Gix6ZXN13fcG03KNGKZo2PY+csPkGC5quDnH5V0JEhDZ78KcDWFsU6u4fr9ktVAdt6P7jWXjcyqdHOZ8+YN4cAeU4lRFNgQvdupIcByYwzPYMgBFHfJm9014HvRqhwIDAQAB"

CONFIGURE POSTFIX

In order to integrate OpenDKIM with Postfix we need to add the following few lines in /etc/postfix/main.cf:

smtpd_milters           = inet:127.0.0.1:8891
non_smtpd_milters       = $smtpd_milters
milter_default_action   = accept
milter_protocol         = 2

(RE)START SERVICES

Add OpenDKIM to your system’s start-up and start opendkim and restart postfix using the following commands:

## service opendkim start
## chkconfig opendkim on
## service postfix restart

TEST THE SET-UP

To test the set-up simply send an email to check-auth@verifier.port25.com and you should receive back an email containing something like this:

==========================================================
Summary of Results
==========================================================
SPF check:          pass
DomainKeys check:   neutral
DKIM check:         pass
DKIM check:         pass

Implementing OpenDKIM to the mailserver set-up with virtual users and domains using Postfix and Dovecot adds another nice feature which makes your emails digitally signed.

But still, there are other features missing like using dovecot sieve rules to filter emails on server-side, scanning emails for viruses etc.. In the next few related articles, we will be adding additional features to the set-up so stay tuned.

Update: Part 6 – How to set-up server-side email filtering with Dovecot Sieve and Roundcube on a CentOS 6 VPS
