Install Redmine on Ubuntu 20.04

Install Redmine on Ubuntu 20.04

Redmine is an open-source and one of the most popular project management and issue tracking systems written in the Ruby on Rails framework. It is a cross-platform and cross-database tool that allows you to manage multiple projects and sub-projects. It offers robust monitoring tools and has integrated support for news, document management, calendars, forum and file management.

Redmine can be integrated with various version control systems and offers a repository browser.

In this tutorial, we will show you how to install Redmine on an Ubuntu 20.04 VPS.

Prerequisites

  • A Ubuntu 20.04 VPS with root access enabled or a user with sudo privileges.
  • Minimum 2GB of RAM.

Step 1: Log in via SSH and Update your System

First, you will need to log in to your Ubuntu 20.04 VPS via SSH as the root user:

ssh root@IP_ADDRESS -p PORT_NUMBER

Replace “root” with a user that has sudo privileges if necessary. Additionally, replace “IP_Address” and “Port_Number” with your server’s respective IP address and SSH port number.

Next, run the following commands to upgrade all installed packages on your VPS:

apt-get update -y
apt-get upgrade -y

Step 2: Install Apache Webserver

Redmine runs on the webserver and written in Ruby on Rails framework. So you will need to install them on your server.

You can run the following command to install the Apache and Passenger module:

apt-get install apache2 libapache2-mod-passenger -y

Once both packages are installed, you can proceed to install the MariaDB server.

Step 3: Install MariaDB Server

Redmine uses MariaDB/MySQL as a database. So you need to install the MariaDB server in your system.

Run the following command to install the MariaDB server from the official Ubuntu repositories:

apt-get install mariadb-server mariadb-client -y

Once installed, enable the MariaDB service to automatically start-up upon server reboot with the following command:

systemctl enable mariadb

Next, secure the MariaDB installation using the following command:

mysql_secure_installation

This script will set the MariaDB root password, disable remote root login and remove anonymous users as shown below:


Enter current password for root (enter for none):
Set root password? [Y/n] Y
New password:
Re-enter new password:
Remove anonymous users? [Y/n] Y
Disallow root login remotely? [Y/n] Y
Remove test database and access to it? [Y/n] Y
Reload privilege tables now? [Y/n] Y

Step 4: Create a Database for Redmine

Next, you will need to create a database and user for Redmine.

First, Log in to your MariaDB console with the following command:

mysql -u root -p

Provide your MariaDB root password when prompt then create a database and user for Redmine using the following command:

MariaDB [(none)]> CREATE DATABASE redminedb CHARACTER SET utf8mb4;
MariaDB [(none)]> GRANT ALL PRIVILEGES ON redminedb.* TO 'redmine'@'localhost' IDENTIFIED BY 'secure-password';

Next, flush the privileges and exit from the MariaDB console with the following command:

MariaDB [(none)]> FLUSH PRIVILEGES;
MariaDB [(none)]> EXIT;

Step 5: Install and Configure Redmine

By default, Redmine is included in the Ubuntu default repository. You can install it with the following command:

apt-get install redmine redmine-mysql

You will be asked to configure the Redmine database as shown below:

Select Yes and hit Enter. You will be asked to provide a password for the database as shown below:

Provide your desired password and hit Enter to finish the installation.

Next, you will need to install Bundler in your system. Bundler provides an environment for Ruby projects by tracking and installing the exact gems and versions that are needed.

You can install it with the following command:

gem install bundler

Once installed, edit the Passenger configuration file located at /etc/apache2/mods-available/passenger.conf:

nano /etc/apache2/mods-available/passenger.conf

Change the file as shown below:


<IfModule mod_passenger.c>
PassengerDefaultUser www-data
PassengerRoot /usr/lib/ruby/vendor_ruby/phusion_passenger/locations.ini
PassengerDefaultRuby /usr/bin/ruby
</IfModule>

Save and close the file. Then, create the Redmine symbolic link to the Apache web root directory:

ln -s /usr/share/redmine/public /var/www/html/redmine

Next, create a Gemfile.lock file and set the ownership to the www-data user:

touch /usr/share/redmine/Gemfile.lock
chown www-data:www-data /usr/share/redmine/Gemfile.lock
chown -R www-data:www-data /var/www/html/redmine

Step 6: Configure Apache for Redmine

Next, you will need to create an Apache virtual host configuration file for Redmine. You can create it with the following command:

nano /etc/apache2/sites-available/redmine.conf

Add the following content:

<VirtualHost *:80>
ServerAdmin admin@example.com
DocumentRoot /var/www/html/redmine
ServerName redmine.example.com
<Directory /var/www/html/redmine>
RailsBaseURI /redmine
PassengerResolveSymlinksInDocumentRoot on
</Directory>

ErrorLog ${APACHE_LOG_DIR}/error.log
CustomLog ${APACHE_LOG_DIR}/access.log combined
</VirtualHost>

Save and close the file. Then, enable the Apache virtual host file and restart the Apache service to implement the changes:

a2ensite redmine.conf
systemctl restart apache2

Step 7: Secure Redmine with Let’s Encrypt SSL

It is a good idea to secure your Redmine with Let’s Encrypt SSL. First, you will need to install the Certbot Let’s Encrypt Client in your system.

Run the following command to install the Certbot client:

apt-get install certbot python3-certbot-apache -y

Once installed, run the following command to download and install the Let’s Encrypt SSL for your domain.

certbot --apache -d redmine.example.com

You will be asked to provide your valid email and accept the term of service as shown below:

Saving debug log to /var/log/letsencrypt/letsencrypt.log
Plugins selected: Authenticator apache, Installer apache
Enter email address (used for urgent renewal and security notices) (Enter 'c' to
cancel): admins@example.com

– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – –
Please read the Terms of Service at
https://letsencrypt.org/documents/LE-SA-v1.2-November-15-2017.pdf. You must
agree in order to register with the ACME server at
https://acme-v02.api.letsencrypt.org/directory
– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – –
(A)gree/(C)ancel: A

– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – –
Would you be willing to share your email address with the Electronic Frontier
Foundation, a founding partner of the Let’s Encrypt project and the non-profit
organization that develops Certbot? We’d like to send you an email about our work
encrypting the web, EFF news, campaigns, and ways to support digital freedom.
– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – –
(Y)es/(N)o: Y

Obtaining a new certificate
Performing the following challenges:
http-01 challenge for redmine.example.com
Waiting for verification…
Cleaning up challenges
Created an SSL vhost at /etc/apache2/sites-available/redmine-le-ssl.conf
Enabled Apache socache_shmcb module
Enabled Apache ssl module
Deploying Certificate to VirtualHost /etc/apache2/sites-available/redmine-le-ssl.conf
Enabling available site: /etc/apache2/sites-available/redmine-le-ssl.conf

Next, you will be asked to choose whether or not to redirect HTTP traffic to HTTPS:

Please choose whether or not to redirect HTTP traffic to HTTPS, removing HTTP access.
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
1: No redirect - Make no further changes to the webserver configuration.
2: Redirect - Make all requests redirect to secure HTTPS access. Choose this for
new sites, or if you're confident your site works on HTTPS. You can undo this
change by editing your web server's configuration.
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Select the appropriate number [1-2] then [enter] (press 'c' to cancel): 2

Type 2 and hit Enter to finish the installation.

Redirecting vhost in /etc/apache2/sites-enabled/redmine.conf to ssl vhost in /etc/apache2/sites-available/redmine-le-ssl.conf

– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – –
Congratulations! You have successfully enabled https://redmine.example.com

Step 8: Access Redmine Web Interface

At this point, Redmine is installed and secured with Let’s Encrypt SSL. Now, open your web browser and type the URL https://redmine.example.com. You will be redirected to the following page:

Click on the Sign in button. You should see the Redmine login page:

Provide the default username and the password as admin / admin, and click on the Login button. You should see the change password screen:

Change the default password with your secure password and click on the Apply button to save the changes. You should see the Redmine dashboard on the following screen:

Congratulations! You have successfully installed Redmine on Ubuntu 20.04 VPS.
